Такаламит пресол с маркуч, твърда връзка и накрайник
Такаламит пресол с маркуч, твърда връзка и накрайник.
Характеристика според производителите:
Grease gun connection, pressure-side
G 1/8’’
Capacity (cm³)
500
Refilling options
400 g grease cartridge, DIN 1284, or bulk grease using a spatula
Diameter of grease piston (mm)
8
Grease pump piston actuation
manually lever operated
Delivery rate/stroke (cm³)
1,2 at a grease density of 0.92 kg/dm³, tested with grease cartridge 400 g (12 511)
Discharge pressure up to (bar)
400
Burst pressure system (bar)
850
Burst pressure grease gun head (bar)
1200
Operation of plunger rod
with L-design handle
Sealing cover
loose
Wall thickness of grease gun tube (mm)
1,0
Lacquering
silver
Dimensions LxWxH (mm)
395 x 120 x 66
Weight (kg)
1,25
Specification
Spout, angled, G 1/8’’, 150 mm (12 735)
Coupler, 4 jaws, G 1/8’’ (12 731)
Special notes
Operates with greases up to NLGI grade 2 at 20°C
plunger with exactly fitting when using bulk grease or cartridge
acc. to DIN 1283
TÜV - certified
Pump piston with high accuracy of fit to the cylinder (no dummy apparent lubrication)
Performance unchanged after 40.000 actuating cycles
Grease gun head, zinc die casting Z 410
sure grip handling due to deep band knurls
safe handle on the plunger rod
Slip resistant handle on grease gun lever
Plunger rod clamp on end cap enables manual pressure to be applied to spring to compress bulk grease, or to force in the plunger in damaged cartridges.
Low effort required for lubrication due to optimum lever efficiency
High-speed ventilation, by half a rotation of the grease gun tube
