MED SEN GAS LW Sas-Sensor Допълнителен безжичен детектор за газ

MED SEN GAS LW Sas-Sensor Допълнителен безжичен детектор за газ с възможност за свързавне към автоаларма

Кратко описание:

Допълнителен безжичен детектор за газ с възможност за свързавне към автоаларма MED 11.552 LW CE

Сензора сработва при наличие на приспивателен газ като етер, GPL (butane and propane)

Homologations
2004/104/CEE
89/336/CEE

Strenghts
The signal is given by an internal buzzer or by a siren - also when it is not active - when it’s coupled to the central unit.
The system is settled to advise at me low presence of gas, before it could become dangerous for the occupants.
The product could be programmed according to 2 calibration levels to choose during the installing which allow to adjust the sensor sensibility according to the position and the use preferred.
SEN GAS LW is fixed on the wall, hidden, integrated into the vehicle

Technical features
Gas to be detected: sleeping gases LPG (propane)
Feeding: 12V
Current consuprion: 10mA (stand-by); 12 mA (alarm)
Operating temperature: -10°C ÷ + 40°C
Humidity: 30 ÷ 95 %
Threshold: 300 PPM in 3 minuts. Reference EN50291
Duration: 10 years
Dimension: 60 x 60 mm
Fixing height: 150/180 cm to detect the sleeping gas, 20/40 cm to detect the GPL
Possibility to connect it to an external buzzer or to a fan not included in the packaging.
Radio signal capacity when coupled to the cental unit MED 6000.LW and MED 7000.LW: 10m
