Matrox RT.X100 Xtreme PCI Video Editing Card

Продавам Matrox RT.X100 Xtreme PCI Video Editing Card

Model: Matrox RT.X100 Xtreme
MPN: RTX100/KIT/IX
P/N: 7089-02 A
MFG P/N: 63039620382
Brand: Matrox

Matrox RT.X100 Xtreme card specifications

General

PCI interface - 3/4-size PCI card
Regulatory compliance - FCC Class B, CE Mark Class B, ACA Class B, BSMI
Class B, VCCI Class B
Nominal card dimensions - 8.4” × 4.2”
Card including bracket - 8.9” × 5.0”

Video

Inputs - 1394 6-pin
Composite video (CVBS), RCA jack
S-Video (Y/C), mini-DIN
NTSC, PAL, and SECAM

Outputs

1394 6-pin
Composite video (CVBS), RCA jack
S-Video (Y/C), mini-DIN
NTSC and PAL

Video formats

ITU-R601
NTSC: 720 × 480 at 29.97 frames/sec
PAL/SECAM: 720 × 576 at 25 frames/sec
4:3 and 16:9 aspect ratios

Video overlay

NTSC and PAL video-in-a-window support on console

Realtime video codec

Capture
DV, DVCAM (NTSC 4:1:1, PAL 4:2:0),MPEG-2 MP@ML IBP from 2 to 10 Mbps Playback
DV, DVCAM (NTSC 4:1:1, PAL 4:2:0)Export
DV, DVCAM (NTSC 4:1:1, PAL 4:2:0),MPEG-2 MP@ML IBP from 2 to 10 Mbps

Audio
Analog audio input/output - Dependent on sound card
Audio sampling method - 16-bit, 48 kHz

Environmental specifications
• Minimum/maximum ambient operating temperatures: 0 to 55º C
• Minimum/maximum storage temperature: -40 to 75º C
• Maximum altitude for operation: 3,000 meters
• Maximum altitude for transport: 12,000 meters
• Operating humidity: 20 to 80% relative humidity (non-condensing)
• Storage humidity: 5 to 95% relative humidity (non-condensing)

Без окомплектовка!

Картата е в перфектно състояние.
Тествана е и работи без забележки.
Пращам с Еконт (преглед и тест )
